Four-axis assembly sorting robot BRTIRPL1003A
Four-axis Robot
Arm Length: 2000mm
Load: 13KG
Four-axis assembly sorting robot
BRTIRPL1003A type robot is a four-axis robot that developed by BORUNTE for assembly, sorting and other application scenarios of light, small and scattered materials. The maximum arm length is 1000mm and the maximum load is 3KG. The protection grade reaches IP50. Dust-proof. The repeat positioning accuracy is ±0.1mm.
Main Specification
Arm Length(mm)：1000
Loading Ability(KG)：3
Accuracy of position(mm)：±0.1
Angle repeat positioning：±0.5°
Maximum allowable moment of inertia of load(kg/㎡)：0.01
Power Source(KVA)：3.3
Net Weight(KG)：104
| Item | Arm Length | Range | Rhythm(/min) | |
| Aaster Arm | Upper | Mounting surface to stroke distance 872.5mm | 46.7° | Stroke：25/305/25（mm） |
| Hem | 86.6° | |||
| End | J4 | ±360° | 150/min | |
