HAKRC F405 D Mini FC
HAKRC F4520D Flight Controller provides great power all in a 20x20mm mounting pattern.
HAKRCF405 D Mini FC
HAKRC F4520D Flight Controller provides great power all in a 20x20mm mounting pattern.The control is equipped with 5 UARTs, MPU6500 IMU, OSD, F.Port and many other functions!Built-in plug-in allows you to easily connect to the DJI FPV Air System.Integrated 16Mb black box, barometer, upgraded Type-C USB interface, greatly improve socket life and reduce the risk of poor contact. Supports various receivers including Sbus,ELRS， PPM, CRSF, DSMX, iBus, DUMD, etc.
FC Specifications：
Product size: 31*28*8mm
Packing size: Φ62*33mm
Installation hole distance: 20*20mm φ4mm
Weight: 6g
Packing weight: 20g
MCU: STM32F405RGT6
IMU:ICM42688
Baro: Infineon DPS310 (I2C2)
OSD: AT7456E (SPI2)
Blackbox: 16MB
B E C：5V/3A ; 9V/2.5A
USB interface: TYPE-C
Input voltage: 3—6S
Firmware: HAKRCF405D
Uart serial port: 5
Assistant software：betaflight-configurator
DJI digital image transmission：support
