IR K Series (P1.25,P1.53,P1.86,P2,P2.5)(640×480mm)

K1.25 K1.53 K1.86 K2 K2.5(640×480mm)

PRODUCT SPECIFICATIONS
Item	K1.25	K1.53	K1.86	K2	K2.5
Pixel pitch	1.25mm	1.538mm	1.86mm	2mm	2.5mm
Pixel density	640000 dots/m²	422500 dots/m²	288906 dots/m²	250000 dots/m²	160000 dots/m²
Module size	320x160mm
LED package	SMD1010	SMD1212	SMD1515	SMD1515	SMD2121
Module resolution(pixels)	256×128	208×104	172×86	160×80	128×64
Module arrangement per cabinet	2×3
Cabinet dimension	640x480x48mm
Cabinet weight(including module)	7.2kg
Cabinet resolution(pixels)	512×384	416×312	344×258	320×240	256×192
Maintenance	Full front service
System backup	Support
White balance brightness	500-800cd/m²
Pixel-livel calibration	Support
Color temperature	6500K(adjustable)
Refresh rate	3840Hz
Viewing angle	160(V/H)
Brightness uniformity	>99%
Grayscale level	16bits
Contrast ratio	5000:1
Scanning mode	1/64	1/52	1/43	1/40	1/32
Working voltage(input)	110-240V,50/60Hz
Max./Avg.Power consumption	500W/m²/165-260W/m²
Storage temperature&humidity(RH)	-20℃-50℃&35-75%
Working temperature&humidity(RH)	-20℃-50℃&35-75%
IP ratings	IP45
Screen temperature rise	≤5℃
Installation	On-wall/recessed/pedestal/suspended/stacked install
Signal output	HDMI/VGA/DVI/DP
Certification	RoHS/FCC/CE
