Outdoor advertising 960*960mm

Dimension : 960 * 960mm Pixel Pitch : P5.7/6/8/10mm

Compare

https://www.techiegoled.com/Outdoor-advertising-960-960mm.html

Solution

High convenience: reliable wall installation, full design for front and rear
maintenance, easy installation, saving installation space; lightweight design,
the weight can be as light as 30kg/m, and the thickness can be as thin as 77mm;
the modules can be interchanged left and right, reducing maintenance costs and
fully Aluminum material, dense corrugated heat sink design, high heat
dissipation efficiency.

mid to high-end outdoor advertising display

Application scenarios

Meet the needs of multiple scenarios for mid- to high-end outdoor advertising
display

Advertising signs, billboard, street view billboards, digital billboards,
transportation hub billboards.

Pixel Pitch	P5.7	P6	P8	P10
Viewing Distance	≥5m	≥6m	≥8m	≥10m
Pixel Points	32928	30240	16800	10752
Brightness	≥4500cd/㎡	≥4500cd/㎡	≥4500cd/㎡	≥4500cd/㎡
Protection Grade	IP65	IP65	IP65	IP65
Viewing Angle	140°	140°	140°	140°
Gray Scale	256	256	256	256
Dimension	960*960	960*960	960*960	960*960
ModuleSize	480*320	480*320	480*320	480*320
Module Points	84*56	80*54	60*40	48*32
Refresh	≥3840HZ	≥3840HZ	≥3840HZ	≥3840HZ
