Ranging Radar Sensor LDRR04

● Frequency: 80GHz
● Ranging range: 40 meters
● Measurement accuracy: ±2 mm
● Communication interface: supports RS485 communication method
● Product form: integral radar with housing or separate PCBA (radar sensor)
● Customization service: Support personalized product customization

Compare

LDRR04 millimeter wave radar is a radar specially designed for hydrographic detection.

The radar adopts FMCW mode, non-contact installation design, small size and compact structure. It has high accuracy, low power consumption and strong anti-interference ability.

Features

● Microstrip antenna version

● Using FMCW mode

● Contactless installation design

● Small size and compact structure

● High accuracy, low power consumption

● Strong anti-interference ability

Application

Lake and river water level measurement, flash flood warning, reservoir water level measurement, sewage pipe network water level measurement, open channel water level measurement, urban waterlogging water level measurement.

It is not affected by temperature, sediment, river pollutants, floating objects on the water surface and other factors.
