SDS series
SDS 0.9/SDS 1.2/SDS 1.5/SDS 1.6/SDS 1.8
| Item | SDS 0.9 | SDS 1.2 | SDS 1.5 | SDS 1.6 | SDS 1.8 |
| Pixel Pitch | 0.9375 mm | 1.25 mm | 1.5625 mm | 1.667 mm | 1.875 mm |
| Max Brightness Calibrated | 300 nits (black) | 400 nits (black) | 400 nits (black) | 500 nits (black) | 500 nits (black) |
| Panel Dimension | 600 x 337.5 x 40 mm | 600 x 337.5 x 40 mm | 600 x 337.5 x 40 mm | 600 x 337.5 x 40 mm | 600 x 337.5 x 40 mm |
| Panel Resolution ( H x V ) | 640 x 360 | 480 x 270 | 384 x 216 | 360 x 202 | 320 x 180 |
| Frame Material | Diecasting Aluminum Alloy | Diecasting Aluminum Alloy | Diecasting Aluminum Alloy | Diecasting Aluminum Alloy | Diecasting Aluminum Alloy |
| Weight Per Panel | 8 kg | 8 kg | 8 kg | 8 kg | 8 kg |
| Power Consumption Max / Average | 1000 W / 500 W Per ㎡ | 1000 W / 500 W Per ㎡ | 800 W / 400 W Per ㎡ | 800 W / 400 W Per ㎡ | 800 W / 400 W Per ㎡ |
| Transparency | Solid | Solid | Solid | Solid | Solid |
| Serviceability | Front / Rear | Front | Front | Front | Front |
| Curving (Concave & Convex) | Custom 10° ~ 15° | N/A | N/A | N/A | N/A |
| SMD Configuration | SMD1616 Black | SMD1212 Black | SMD1212 Black | SMD1212 Black | SMD1515 Black |
| Physical Density | 1,137,777Pixels / ㎡ | 640,000 Pixels / ㎡ | 409,600 Pixels / ㎡ | 359,111 Pixels / ㎡ | 284,444 Pixels / ㎡ |
| Viewing Angle ( H / V) | 160° / 140° | 140° / 140° | 140° / 140° | 140° / 140° | 140° / 140° |
| Refresh Rate | 3840 Hz | 3840 Hz | 3840 Hz | 3840 Hz | 3840 Hz |
| Gray Scale | 14 bit | 14 bit | 14 bit | 14 bit | 14 bit |
| Scan Ratio | 1/60 | 1/27 | 1/54 | 1/26 | 1/60 |
| Operational Temp / Humidity | – 20° ~ 45°C / 10-90% RH | – 20° ~ 45°C / 10-90% RH | – 20° ~ 45°C / 10-90% RH | – 20° ~ 45°C / 10-90% RH | – 20° ~ 45°C / 10-90% RH |
| Storage Temp / Humidity | – 40° ~ 60°C / 10-90% RH | – 40° ~ 60°C / 10-90% RH | – 40° ~ 60°C / 10-90% RH | – 40° ~ 60°C / 10-90% RH | – 40° ~ 60°C / 10-90% RH |
| IP Rating (Front / Rear) | IP30 / IP30 Indoor | IP30 / IP30 Indoor | IP30 / IP30 Indoor | IP30 / IP30 Indoor | IP30 / IP30 Indoor |
*Note: The specifications are for reference, actual values may vary.
