Selective wave soldering machine

Overview

Unique spray process, stable welding selection effect, small batch production of preferred welding equipment, low cost, high flexibility

Product features

Special designed point flux injection;

High precision, high stability selection spot welding (single and double head optional)

Nozzle automatic cleaning , automatic calibration of jet height, automatic addition of solder and miniaturization design;

Configure the AIVS manufacturing platform;

Realize the online repair function by connecting AOI

Type	Specification	Selective wave soldering machine
Technical parameter	Machine size	L800W1400H1400mm
	Mechanical pump groove	Standard：single cylinder×1个
	Spray nozzle diameter	φ3-12mm
	Wave height	Max:5mm
	PCB gap	Min:3mm
	Tin furnace capacity	8KG/ Solder furnace
	Soldering temperature	Max : 320℃
	Temperature control accuracy	±1℃
	Heating time	40Min/（300℃)
	Tin furnace power	1KW/ Solder furnace
	Moving speed	X/Y：2 – 400 mm/s
	Moving speed	Z：2 – 50 mm/s
	Wave accuracy	±0.5mm
	Repeated accuracy	±0.05mm
	Spray width	2-8 mm
	Size of spray nozzle	130um
	Spray way	Linear
	Pressure	0.5Mpa
	Nitrogen consumption	1.5m/H
	Particles cleanliness	≥99.99%
	Nitrogen preheating temperature	MAX:350℃
	Temperature control accuracy	±1℃
	Process visualization	CCD visible
	Data import	Measure Gerber、Images imported online
	Power	3P5W,380VAC
	Frequency	50/60Hz
	Consumption	4.5KW
	Air supply	0.5Mpa
	Automatic solder adding device	Option
	Nozzle automatic cleaning device	Option
	Spray height correction	Option
	AIVS Intelligent manufacturing platform	Option
