HAKRC F7230S flight controller

The PCB is made of high-end 6-layer 1oZ thickened copper skin, which has strong anti-interference ability.

  HAKRC F7230S flight controller

1. The PCB is made of high-end 6-layer 1oZ thickened copper skin, which has strong anti-interference ability.

2. Adopt double gyroscope design to reduce the error of one gyroscope.

3. Adopt industrial-grade LDO, high temperature resistance.

4. Use in-line connectors, easy to install, solder-free.

5. The board comes with 4 channels of programmable LED lights, which can switch LED lighting effects freely.

6. Reserve the 10V power supply of the external LED strip light, and the remote control channel can be customized for the switch control of the strip light.

7. The power supply of the image transmission can be set up by the ground station to open or close the power supply of the video transmission freely, which is convenient for the ground parameter adjustment.

8. Adopt high-quality Japanese Murata capacitors, strong filtering performance.

9. Onboard integrated 2.4G receiver

  FC Specifications:

Product size: 36* 36mm

Packing size: Φ64*64*35mm

Installation hole distance: 30.5mm-30.5mm φ4mm

Weight: 8.5g

Packing weight: 38.5g

MCU: STM32F722RET6

IMU:ICM42688

OSD:AT7456E

Blackbox: 16MB

BEC:5V/3A
BEC:10V/2.5A

USB interface: TYPE-C

LED: Adjustable LED light

Sensor: Built-in current sensor

Firmware version: HAKRCF722V2

Receiver: Frsky / Futaba / Flysky / TBS Crossfire / DSMX: DSM2 receiver
