KPR Zeolite Rotary Concentrator
Under low temperature conditions, high air volume organic waste gas passes through the KPR Zeolite Rotary Concentrator, and VOC molecules adsorb its surface.
The KPR enrichment system-KPR Zeolite Rotary Concentrator Processing process
This set of exhausted air purification equipment adopts advanced high air
volume tertiary filtration system + zeolite runner adsorption concentration +
desorption + high temperature incineration " process, using the principle of
large zeolite specific surface area and different molecular forces under
different temperature conditions. Under low temperature conditions, the organic
exhausted air through the zeolite molecular sieve wheel, VOC molecule adsorption
on its surface, after the exhausted air through the zeolite wheel can be
directly discharged. The zeolite wheel with a large number of VOC enters the
high temperature desorption area, using the high temperature clean air with
small air volume to desorattach the VOC molecules on the zeolite wheel, forming
a high concentration of waste gas, into the back end of the exhausted air
oxidation system thermal oxidation treatment, the purified exhausted air can be
directly discharged.
KPR Zeolite Rotary Concentrator Equipment Characteristics
1. The rotary runner is simple because of its simple structure
2. Can continuously concentrate the organic solvents
3 Suitable for the treatment of low concentration gale volume, low operating
cost
4. Use the hydrophobic molecular sieve as the runner adsorption material,
with non-combustible
5. Treat multiple solvents (Vocs) simultaneously
6. Can achieve 3-15 times of concentration, (according to different mining
conditions can be 20-30 times of concentration
7. Treatment air volume is 10000m3200000m3
Level 3 filtration device
Function Introduction
1. Because the exhausted air contains oil fog and dust and other solid
particles, and the zeolite molecular sieve has strict requirements on the
content and particle size of the exhausted air, so the zeolite wheel is set
before: primary, medium and high three filters.
2. The filter material is composed of three-level medium and high efficiency
filter. The dust purification rate of 99% of more than 0.5um in the gas is
classified as modular design and convenient combination, installation and
disassembly, so that the equipment has good implementation.
Related products
-
Contact UsThe project plans to build a 60-ton-day hazardous waste incineration device of Jiangxi Brothers Pharmaceutical Co., LTD., for the incineration and treatment of the hazardous waste generated by the plant.
-
Contact UsThe zwitterionic polyacrylamide is formed by copolymerization of the cationic monomer, acrylamide monomer, and hydrolysis agent.
-
Contact UsDF-03 is modified starch by inserting hydration groups and high temperature stabilizer to improve the water solubility and temperature resistance (up to 135 ℃). And ensure its good fluid loss performance under both low and high temperature. DF-03 is an environmental friendly, low viscosity, salt resistance (up to saturation) filtration reducer. Its recommend dosage is 1.0%-2.0%.
-
Contact UsIt is used Can-making/Metal sheet Painting and Printing Ovens. According to the specifications of the printed and coated products, a large number of C-shaped buckles and rollers (made of specialized food grade imported materials) are installed on the inner bracket and edge ears of the wicket, allowing the sheet (aluminum plate) to dry and run in a separate state from the wicket, effectively avoiding the problem of dot shaped scratches and burns in the printed and coated products.
-
Contact UsRTO is an air pollution control system which collecting the exhausted air through the safety air valve into the oxidation bed with the temperature over 820℃ to oxidation the organic waste gas into carbon dioxide and water.
It is used
1. Industrial and mining conditions with high and low concentrations of organic solvents in the treatment of emitted gases
2. Industrial and mining conditions with requirements for the collection and treatment of unorganized emissions
3. Equipment conditions without waste heat utilization value
