FSGJ30D Progressive type safety gear(Single lift)
FSGJ30D Single Lift Progressive Type Safety Gear
https://www.xizi-ec.com/FSGJ30D-Progressive-type-safety-gear-Single-lift.html
Type：FSGJ30D
Rated load range(P+Q)(kg)：900~3600
Rated speed range(m/s)：0.25~2.5
Activation speed range(m/s)：0.32~3.23
Guide rail width(mm)：10、15.88、16
|
Lift mode |
Bottom beam mounting interface dimensions |
||||||
|
A |
B |
C |
E |
F |
D1 |
D2 |
|
|
Left Side lift |
33.5 |
118 |
71 |
48 |
30 |
4×M16 |
2×Φ12 |
